Product parameters

Speed: 1000-60000rpm adjustable

Bounce accuracy: within 1 μ m

Floating method: Radial 360 °+/-5 ° Axial 5mm

Floating pressure: 0.05-0.2Mpa

Overall weight: 2.35kg

Output power: 350W

Power supply: 100-220V

Cooling method: air cooling

Tool changing method: Pneumatic tool changing

Clamping tool shank diameter: 0.5-6.0mm

Application scope

(1) Cast iron, steel parts, aluminum alloys, resins, etc;

(2) Burrs at the water outlet below 3mm;

(3) Joint lines, welding slag, welds, burrs, etc;

(4) Processed flanging;

(5) Chamfering below C3, removal of burrs on complex workpieces.

Product Features

(1) Flexible 360 ° steering, with a 5mm float in the Z direction;

(2) Can be used to hold tools with robotic arms, and can also fix the tools. The robot can handle workpieces for deburring processing;

(3) During the deburring process, the product can be automatically suctioned and processed adaptively; Effectively protect cutting tools and reduce debugging difficulty;

(4) Recommended consumables: end mills, rotary files, taper milling cutters, wire brushes, diamond grinding heads, etc.
